Order no. 89010258
Tubular dispenser RE-H2-290 - 2005

The statically heated crockery dispenser (for round/square crockery), made of stainless steel with a polycarbonate lid, double-walled insulation, with 2 dispensers for round crockery with a diameter of 282 mm, with a platform, safety pushing handle, 4 corner bumpers, stainless steel castors (2 swivel castors and 2 swivel castors with brakes).

Service videos Downloads
Product profile

The tubular dispenser with a static heater for the heating, interim storage and transport of crockery items in an adjustable dispenser. The spring force can be easily adjusted by hand according to the crockery weight. Also with integrated overheating protection for perfect safety and including a polycarbonate lid for hygienic protection of the crockery items*.

As an additional accessory, the single-walled stainless steel lid hood or complete all-round impact protection for extra robustness and plastic-coated inner panelling. Also with CNS castors on request.

Properties
GTIN/EAN 4007537055899
Material stainless steel 1.4301 (CNS)
Weight 58 kg
Dimensions 955 x 480 x 1030 mm
Heating range +30°C to +110°C
Chamber dimensions (clear opening) 290 x 290 mm
Number of tubes 2
Lids Included (2x in plastic)
Rated voltage 1N AC 230 V 50/60 Hz
Connected load 1.700 W
Plug type Safety switch (type F)
Country-specific plug on request
Cable type spiral cable
Cable length 2500 mm
Protection class IPX5
Sockets Blind socket
Functions heated
Heating/cooling mode statically heated
Impact protection 4 corner bumpers
Wheel diameter 125 mm
Castors 2 fixed-; 2 swivel castors with brakes
Max. loading capacity 150 kg
Order number 89010258

USP

  • Rustproof, high-quality, hygienic stainless steel, brushed matt finish.
  • Sturdy, smooth-running platforms.
  • Tilt and twist-proof, with a robust unstacking mechanism.
  • Body with double-walled insulation, low loss of heat.
  • Flexible and precise adjustment by hand.
  • Adjustable uniform serving height, with heat-resistant tension springs.
  • Mobile with fixable stainless steel castors and a safety pushing handle.
  • Corner bumpers for impact protection as well as a shockproof switching element.
  • Removable dispenser inserts, easy to clean.
  • Exterior with a sealed lid, suitable for cleaning with a high-pressure cleaner, splash-proof (IPX5).
The Rieber System Basis

Our versatile GN operating system

The container standard in every commercial kitchen - our high-quality and robust Gastronorm range offers you an extensive selection of different container & lid variants that you can combine and use flexibly for every application. Ideal for hygienic and standardised storage, transport and serving of food - in almost any size and depth, universally compatible in all GN systems and products.

Rieber has a large number of unique innovations in addition to the "GN classics". Like our highly efficient cooking pot thermoplates® made of conductive SWISS-PLY multi-layer material or our 100% reliable watertight plug-in lid as well as the vacuumable vaculid® lid.
