thermoport® s/s 1600 refrigerated R290 // Products

GTIN/EAN	4007537166045
Production	Made in Germany
Material	stainless steel 1.4301
Dimensions	492 x 769 x 1130 mm
Weight	50 kg
GN size	GN 1/1
Support rails	16
Distance between supports	37 mm
Refrigeration range	+2°C to +8°C
Refrigerant	R290
Rated voltage	1N AC 230 V 50/60 Hz
Connected load	265 W
Plug type	Safety switch (type F)

GTIN/EAN

4007537166045

Production

Made in Germany

Material

stainless steel 1.4301

Dimensions

492 x 769 x 1130 mm

Weight

50 kg

GN size

GN 1/1

Support rails

Distance between supports

37 mm

Refrigeration range

+2°C to +8°C

Refrigerant

R290

Rated voltage

1N AC 230 V 50/60 Hz

Connected load

265 W

Plug type

Safety switch (type F)

Cable type	spiral cable
Cable length	2000 mm
Protection class	IPX3
Functions	refridgerated
Heating/cooling mode	silent cooling
Impact protection	4 corner bumpers
Wheel diameter	125 mm
Castors	2 fixed-; 2 swivel castors
Castor type	Rustproof
Max. loading capacity	62 kg
Capacity with GN containers	70,4 L
Hygienic design	H3
Order number	85010616

Cable type

spiral cable

Cable length

2000 mm

Protection class

IPX3

Functions

refridgerated

Heating/cooling mode

silent cooling

Impact protection

4 corner bumpers

Wheel diameter

125 mm

Castors

2 fixed-; 2 swivel castors

Castor type

Rustproof

Max. loading capacity

62 kg

Capacity with GN containers

70,4 L

Hygienic design

Order number

85010616

USP

Rustproof, high-quality, hygienic stainless steel (interior and exterior).

Interior tightly welded with seamlessly deep-drawn support rails in hygienic design H3.

With natural and therefore environmentally friendly and powerful refrigerant R290.

Double-walled insulation, low loss of cold.

Uniform cooling distribution, even when fully loaded.

Mobile with robust, fixable castors and a push handle.

Bumpers for impact protection.

Suitable for outdoor use, splash-proof (IPX3).

Removable door seal, quick and easy cleaning.

Hygienic surfaces.

Our GN operating system is the standard in every commercial kitchen. With a wide range of Gastronorm containers and lids, it offers maximum flexibility for storage, transport, serving and more - hygienic, robust and available in many sizes and depths.

In addition to the tried and tested GN classics, Rieber focuses on innovation: from the efficient thermoplates® cooking pot made of SWISS-PLY multi-layer material to the 100% watertight push-fit lid and the vacuumable vaculid® lid. New: the revolutionary GN auto container, which saves around 60 % of storage space and enables automated processes via robotisation.

YourLogo GN - As unique as your business

We use the latest laser technology to personalise GN containers & lids with your individual logo - for clear recognition, a professional look and more individuality in the kitchen.

GN CONNECT - digitally organised in the CHECK TRACE reusable system

The lasered smart Rieber QR code, with the GS1 Digital Link - ensures full transparency, traceability and error-free & time-saving order picking.

CHECK HACCP convinces the University Hospital in Mannheim

Head Chef Andreas Reuther and Sebastian Dietrich are impressed in many ways – digital HACCP documentation has resulted in significant time savings. Not only the WKD (German Association for the Health and Medical Care) praises the system, but users also provide positive feedback, as it has been adapted to the clinic's individual requirements and concept. The photo function, for example, has created complete transparency and clarity. The quality of goods receiving and supplier management has also improved significantly.
